M1083 with tank and pump unit
HermannB
Visit this Community
Bayern, Germany
Joined: October 14, 2008
KitMaker: 3,505 posts
Armorama: 3,477 posts
Posted: Thursday, July 11, 2019 - 06:40 PM UTC
Hi Gang,
I came across this pic:

https://www.dvidshub.net/image/5558700/operation-hickory-sting-nc-guard-soldiers-load-up-and-move-out-ntc-exercise

Do anyone know how much of these were converted? Are there more pics to find? I guess the proposed M1091 FMTV fuel tanker with HEMTT tank and pump is cancelled?
HermannB
Visit this Community
Bayern, Germany
Joined: October 14, 2008
KitMaker: 3,505 posts
Armorama: 3,477 posts
Posted: Thursday, July 11, 2019 - 06:47 PM UTC
One more tanker from NTC training.

https://www.dvidshub.net/image/5561111/operation-hickory-sting

Anyone takes the challenge?
Frenchy
Visit this Community
Rhone, France
Joined: December 02, 2002
KitMaker: 11,972 posts
Armorama: 11,767 posts
Posted: Thursday, July 11, 2019 - 07:33 PM UTC

Quoted Text

Anyone takes the challenge?



http://members.toast.net/toledoplasticmodelers/gallery/JA/M1083.htm

H.P.
HermannB
Visit this Community
Bayern, Germany
Joined: October 14, 2008
KitMaker: 3,505 posts
Armorama: 3,477 posts
Posted: Thursday, July 11, 2019 - 07:38 PM UTC
I was refering to the HEMTT, not the FMTV.

What is this True Models he used?
BTW Whats the designation of the fuel tank on the M1076 trailer?
Frenchy
Visit this Community
Rhone, France
Joined: December 02, 2002
KitMaker: 11,972 posts
Armorama: 11,767 posts
Posted: Thursday, July 11, 2019 - 09:25 PM UTC

Quoted Text

I was refering to the HEMTT, not the FMTV.



So why did you mention the M1083 in the post title ?

I guess this trailer is part of the Modular Fuel System (MFS) :

https://www.leonardodrs.com/media/6278/mfs_datasheet.pdf

Here's a similar one :



H.P.
HermannB
Visit this Community
Bayern, Germany
Joined: October 14, 2008
KitMaker: 3,505 posts
Armorama: 3,477 posts
Posted: Thursday, July 11, 2019 - 10:04 PM UTC
BTW The fuel tank/pump unit from PSM could only be used with mods. the filler cap of the tank is different.
Frenchy
Visit this Community
Rhone, France
Joined: December 02, 2002
KitMaker: 11,972 posts
Armorama: 11,767 posts
Posted: Thursday, July 11, 2019 - 10:24 PM UTC
I guess the PSM (or the MMK) tanks are 600 gallon models :



whereas those with recessed fillers are 500 gallon ones :


H.P.
165thspc
#0
Visit this Community
Kentucky, United States
Joined: April 13, 2011
KitMaker: 8,461 posts
Armorama: 7,874 posts
Posted: Thursday, July 11, 2019 - 10:49 PM UTC
(This is probably obvious to all but here goes . . . . )

The trailer mounted modular fuel tank (a tank rack) is a containerized fuel storage/dispensing unit and can be loaded/unloaded off the M1076 trailer by a HEMTT with LHS (Load Handling Equipment),

There is also a containerized water tank version (also referred to as a tank rack) with pump and purification equipment called a Hippo.





HermannB
Visit this Community
Bayern, Germany
Joined: October 14, 2008
KitMaker: 3,505 posts
Armorama: 3,477 posts
Posted: Friday, July 12, 2019 - 01:58 AM UTC

Quoted Text

I guess the PSM (or the MMK) tanks are 600 gallon models :



whereas those with recessed fillers are 500 gallon ones :


H.P.



Damn, Frenchy, now I have to go back to the drawing board..

Hmmm... the best way (not the cheapest) is to get 4 tanks, cut them horizontal and glue the two upper halves together.
40 Euros for Trumpeter M1083
plus
76 Euros for two PSM tank sets
plus
40 Euros for Legend FMTV update
Frenchy
Visit this Community
Rhone, France
Joined: December 02, 2002
KitMaker: 11,972 posts
Armorama: 11,767 posts
Posted: Friday, July 12, 2019 - 07:11 AM UTC

Quoted Text

Damn, Frenchy, now I have to go back to the drawing board..



Maybe the TM would help ?

https://www.liberatedmanuals.com/TM-10-4930-236-13-and-P.pdf

H.P.
HermannB
Visit this Community
Bayern, Germany
Joined: October 14, 2008
KitMaker: 3,505 posts
Armorama: 3,477 posts
Posted: Friday, July 12, 2019 - 01:51 PM UTC

Quoted Text


Quoted Text

Damn, Frenchy, now I have to go back to the drawing board..



Maybe the TM would help ?

https://www.liberatedmanuals.com/TM-10-4930-236-13-and-P.pdf

H.P.



Definitly, Thank you.
